Feature
* 適配模組:
NVIDIA Jetson Nano/TX2NX Module
* 通用接口:
1x RJ45, 2x USB 3.0, 1x USB 2.0, 1x HDMI and 1x USB Micro B
* 外設(shè)支持:
1x TF slot, 1x Nano SIM, 2 RS232, 3x GPIO, 1x GPO
* Input Power: DC +9V~+24V
4G communication module, WIFI/Bluetooth module, Video capture/output module, Multi I/O module.
|
Product Name |
TX2NX-SYS-2006 |
|
Jetson Module Supported |
NVIDIA Jetson TX2 NX |
| AI Processor |
1.33 TFLOPS |
| GPU |
256-core NVIDIA Pascal? architecture GPU |
| CPU |
Dual-Core NVIDIA Denver 2 64-Bit CPU and Quad-Core Arm® Cortex®-A57 MPCore processor |
|
Memory |
8GB 128-bit LPDDR4x 59.7GB/s |
|
Storage |
16GB eMMC 5.1 |
|
Video Encode |
1x 4K60 (H.265) 3x 4K30 (H.265) 4x 1080p60 (H.265) |
|
Video Decode |
2x 4K60 (H.265) 7x 1080p60 (H.265) 14x 1080p30 (H.265) |
|
CSI Camera |
Up to 5 cameras (12 via virtual channels)12 lanes MIPI CSI-2D-PHY 1.1 (up to 30 Gbps) |
|
Networking |
1x Gigabit Ethernet(10/100/1000 BAST-T) RJ45 |
|
USB |
2x USB 3.0 Type-A 1x USB 2.0 1x Micro USB |
|
Display |
1x HDMI |
| Other I/O |
1x Micro TF，1x Nano SIM，2x RS232，3x GPIO，1x GPO |
|
Mechanical |
160mm x 133mm x 90mm |
| Weight | 1078g |
|
Operating Temperature |
-20℃~+65℃ |
| Power | DC +9V～+24V |
